Main

Main Input Voltage

200 V
208 V
230 V

Output voltage

208 V

230 V

PDU Type

Metered

Input Connection Type

IEC 60320 C14

Number of rack unit

1U

Cable length

6.50 ft (1.98 m)

Provided Equipment
Cord retention bracket(s)
Installation guide
Rack Mounting brackets
User Manual

Input Frequency

50/60 Hz

Line Rated Current

0.416666667

Input current limits

15 A

Load Capacity

2300 VA

Maximum Total Current Draw per Phase

0.416666667

Number of power socket outlets

8 IEC 60320 C13

Protection Type

Without circuit breaker

Complementary

Height

1.7 in (44 mm)

Width

17.5 in (444 mm)

Depth

4.02 in (102 mm)

Net Weight

3.81 lb(US) (1.73 kg)

Mounting Location

Front
Rear

Mounting preference

No preference

Mounting Mode

Rack-mounted

Mounting position

Horizontal

Different voltages and corresponding amperages

10 A - 230 V
12 A - 208 V

Environmental

Product Certifications

cUL Listed
C-tick
CE
CSA
GOST
UL Listed
VDE
VCCI

Standards

FCC Part 15 class A
UL 60950

Ambient Air Temperature for Operation

23…113 °F (-5…45 °C)

Relative Humidity

5…95 %

Operating altitude

0...10000 ft

Ambient Air Temperature for Storage

-13…149 °F (-25…65 °C)

Storage Relative Humidity

5…95 %

Storage altitude

0…50000 ft (0…15240 m)

Ordering and shipping details

GTIN

731304246596

Packing Units

Unit Type of Package 1

PCE

Nbr. of units in pkg.

1

Package 1 Height

2.5 in (6.4 cm)

Package 1 Width

18.5 in (47 cm)

Package 1 Length

13.3 in (33.7 cm)

Package weight(Lbs)

6.402 lb(US) (2.904 kg)

Contractual warranty

Warranty (in months)

12
