Description
A UniFi Console designed for managing massive-scale UniFi Networks.
Manage 1,000+ UniFi Network devices and 10,000+ clients
(1) 10G SFP+ and (1) GbE RJ45 LAN port
(2) 550W redundant power supply units (PSUs)
Full 1U form factor
Bluetooth for instant setup
|
Overview |
||
|
Dimensions |
787 x 43.7 x 481.4 mm (31 x 1.7 x 19") |
|
|
UniFi Application Suite |
||
|
Network |
✓ |
|
|
Managed UniFi Devices |
1000 |
|
|
Simultaneous Users Connected |
10000 |
|
|
Port Layout |
||
|
1 GbE RJ45 |
2 (1G/100M/10M) |
|
|
10G SFP+ |
1 (10G/1G) |
|
|
Form Factor |
Rack Mount (1U) |
|
|
Redundancy |
(2) Hot-Swappable PSUs |
|
|
Hardware |
||
|
Max. Power Consumption |
190W |
|
|
Power Method |
Universal AC input, 100-240V AC, 7A Max., 50/60 Hz |
|
|
Power Supply |
(2) Hot-Swappable AC/DC 550W PSU |
|
|
Supported Voltage Range |
Universal AC input, 100-240V AC, 7A Max., 50/60 Hz |
|
|
Processor |
16-core Intel® Xeon®-SP Gold 5218 at 2.3 GHz |
|
|
System Memory |
(2) 16 GB |
|
|
On-board Storage |
(1) 256 GB, M.2 2280 SATA |
|
|
Weight |
13.1 kg (28.9 lb) |
|
|
Enclosure Material |
Front panel: Aluminium Chassis: SGCC steel |
|
|
Mount Material |
SGCC steel |
|
|
LCM Display |
1.3" touchscreen |
|
|
Management |
Ethernet Bluetooth |
|
|
LEDs |
||
|
Ethernet |
✓ |
|
|
SFP+ |
✓ |
|
|
CRPS |
✓ |
|
|
Button |
Factory Reset |
|
|
ESD/EMP Protection |
Air: ± 15kV, contact: ± 8kV |
|
|
Ambient Operating Temperature |
0 to 35° C (32 to 95° F) |
|
|
Ambient Operating Humidity |
8 to 90% noncondensing |
|
|
NDAA Compliant |
✓ |
|
|
Certifications |
CE, FCC, IC |
|
|
Software |
||
|
Application Requirements |
||
|
UniFi Network |
Version 7.3.83 and later |
|
