Description
Smart Switch, 1 x Gigabit LAN, 16 x SFP+ cages, Dual Core 800MHz CPU, 1GB RAM, 1U rackmount passive cooling case, Dual Power Supplies.
The new Cloud Router Switch 317-1G-16S+RM is a rack-mountable manageable switch with Layer3 features, it has 16 SFP+ ports for high performance 10GbE connectivity and a 1GbE copper port for management.
CRS317-1G-16S+RM is powered by a next generation switching chip, giving you wire speed performance for all sixteen 10GbE ports with any Ethernet frame size. New features such as hardware-based Spanning Tree Protocol and Link Aggregation (LACP) provide enhanced protection and true professional performance for your demanding network.
The unit has dual redundant power supplies and passive cooling case - for hot environments two redundant fans will automatically keep the system cool if needed.
|
Specifications |
|
|
Product code |
CRS317-1G-16S+RM |
|
Architecture |
ARM 32bit |
|
CPU |
98DX8216 |
|
CPU core count |
2 |
|
CPU nominal frequency |
800 MHz |
|
Switch chip model |
98DX8216 |
|
Dimensions |
443 x 224 x 44 mm |
|
RouterOS license |
6 |
|
Operating System |
|
|
Size of RAM |
1 GB |
|
Storage size |
16 MB |
|
Storage type |
FLASH |
|
MTBF |
Approximately 200'000 hours at 25C |
|
Tested ambient temperature |
-20°C to 60°C |
|
Powering |
|
|
Number of AC inputs |
2 |
|
AC input range |
100-240 |
|
Number of PSU slots |
2 |
|
Frequency (Hz) |
50-60 |
|
Max power consumption |
44 W |
|
Cooling type |
2 fans |
|
Ethernet |
|
|
10/100/1000 Ethernet ports |
1 |
|
Fiber |
|
|
SFP+ ports |
16 |
|
Peripherals |
|
|
Serial console port |
RJ45 |
|
Other |
|
|
CPU temperature monitor |
Yes |
|
Beeper |
Yes |
|
Certification & Approvals |
|
|
Certification |
CE, EAC, ROHS |
|
Warranty |
|
|
Warranty |
1 Year |
