EAP102

Edgecore
Price:
K 1,028,000

In stock at Mega Mall. Dispatch in 1-2 business day.

Description

Wi-Fi 6 Indoor Access Point

  • Concurrent Dual-Band 2.4GHz & 5GHz
  • 4×4:4 UL MU-MIMO
  • Support BLE
  • 1 x 2.5GbE PoE WAN
  • 1 x 2.5GbE LAN
  • Support ecCLOUD

EAP102 is an enterprise-grade, concurrent dual-band Wi-Fi 6 indoor access point. EAP102 supports 4 x 4 : 4 uplink and down link MU-MIMO between the AP and multiple clients, with up to 2.9 Gbps aggregated data rate. EAP102 is equipped with Bluetooth Low Energy (BLE) radio enabling value-added applications such as iBeacon.

EAP102 can be operated as standalone mode or managed by Edgecore ecCLOUD.

WI-FI

Standards:

• 802.11ax (Wi-Fi 6)
• Concurrent dual-band 2.4 GHz & 5 GHz

Radio Chains:

• 2.4 GHz: 2 x 2
• 5 GHz: 4 x 4

Spatial Streams:

• 2.4 GHz: 2; MU-MIMO support
• 5 GHz: 4; MU-MIMO support

Aggregate Conducted Transmit Power:

• 2.4 GHz: Up to 23 dBm
• 5 GHz: Up to 26 dBm

Channelization:

• 2.4 GHz: 20 / 40 MHz

Frequency Range:

• 2.400 – 2.483 GHz
• 5.150 – 5.850 GHz

Operating Channels:

• 2.4 GHz: 1 –11 (US), 1 –13 (Europe), 1 –13 (Japan)
• 5 GHz: 36 –165 (US), 36 –140 (Europe), 36 –144 (Japan)

ESSIDs:

• Up to 16 per radio (32 total)

ANTENNA

Type:

• 4 x Built-in antenna (2.4 GHz & 5 GHz)

Gain:

• 5.5dBi (2.4 GHz, BLE)
• 7.6 dBi (5 GHz)

MECHANICAL

Dimensions (L x W x H):

• 19.5 cm x 20.1 cm x 3.98 cm

Weight:

• 0.7 kg

Mounting:

• Wall/Ceiling/T-bar mount (Mounting kit included)

HARDWARE

Power:

• DC Input: 12V / 2.0A (Power adapter included)
• PoE: 802.3at compliant (PoE injector optional)

LED Indicator:

• Uplink / 2.4G-WiFi / 5G-WiFi / Power

Buttons:

• Restart/ Reset

Environmental Conditions:

• Operating Temperature: 0°C (32°F) to 45°C (113°F)
• Operating Humidity: 5% to 95% non-condensing

Power Consumption:

• 25W max (22W when powered by DC)

Mounting:

• Wall/Ceiling/T-bar mount (Mounting kit included)

Physical Data Rate:

• Up to 574 Mbps (2.4 GHz)
• Up to 2400 Mbps (5 GHz)

INTERFACES

Uplink:

•1 x 10/100/1000/2.5GBase-T Ethernet, Auto MDIX, RJ-45 with 802.3at PoE

LAN:

• 1 x 10/100/1000/2.5GBase-T Ethernet, Auto MDIX, RJ-45

Console:

• 1 x RJ-45 Port

USB:

• 2 x USB 2.0 Port (One USB port work at a time)

CERTIFICATIONS

Certifications

• FCC
• CE
• LVD
• NCC
• BSMI
• VCCI
• JATE
• TELEC
• IC
• C-Tick
• Philippines
• Thailand

WIRELESS FEATURES

Wireless Features

• 802.11 k/r
• Orthogonal Frequency Division Multiple Access (OFDMA)
• Client Isolation
• Open Mesh

NETWORK FEATURES

Network Features

• Spanning Tree Protocol (STP)
• Dynamic Host Configuration Protocol (DHCP)
• 802.1q
• Access Control List (ACL)
• Network Address Translation (NAT)
• Dynamic VLAN
• Link Layer Discovery Protocol (LLDP)

SECURITY

Security

• WPA-Personal (AES)
• WPA-Enterprise (AES)
• WPA2-Personal (AES)
• WPA2-Enterprise (AES)
• WPA3-Personal (AES)
• WPA3-Personal Transition (AES)
• WPA3-Enterprise (AES)
• WPA3-Enterprise transition (AES)
• MAC Address Authentication

MAINTENANCE

Maintenance

• Network Time Protocol (NTP)
• Standalone
• Management by ecCLOUD
• Management by EWS-Series Controller (Complete tunnel)
• SSH
• QR Code Onboarding
• SNMP v2c
• Remote Syslog

QOS

QoS

•  RSSI Threshold (Optimal Client Filtering)

MOBILITY

Mobility

•  OpenRoaming (Hotspot 2.0 R1)

OTHER FEATURES

Other Features

• Target Wake Time (TWT)
• iBeacon
• Hotspot Captive Portal
• Dynamic Authorization (DAE)

Warranty

Warranty

1 Year
