Description
Fully managed, 10-gigabit aggregation switch with (12) SFP+ ports and (4) 10 GbE RJ45 ports.
|
Mechanical |
|
|
Dimensions |
443 x 221 x 43 mm (17.4 x 8.7 x 1.7") |
|
Weight |
Without mount brackets: 2.6 kg (5.8 lb) |
|
With mount brackets: 2.7 kg (6 lb) |
|
|
Hardware |
|
|
Networking interfaces |
(12) 1/10 Gbps SFP+ Ethernet ports |
|
(4) 1/10 Gbps RJ45 Ethernet ports |
|
|
Management interface |
(1) RJ45 serial port, Ethernet In-Band |
|
Total non-blocking line rate |
160 Gbps |
|
Power method |
100–240V AC, 50/60 Hz, universal input |
|
DC 56W, 25–16V, with 2.5 mm, DC power inline connector |
|
|
Power supply |
AC/DC, internal, 56W |
|
Supported voltage range |
100–240V AC |
|
25–16V DC |
|
|
Max. power consumption |
36W (Excludes SFP/SFP+ module) |
|
ESD/EMP protection |
Air/contact: ± 24 kV |
|
Rackmount |
Yes, 1U high |
|
LEDs |
SFP+ ports: speed/link/activity |
|
RJ45 ports: speed/link/activity |
|
|
Shock and vibration |
ETSI300-019-1.4 Standard |
|
Ambient operating temperature |
-5 to 40° C (23 to 104° F) |
|
Ambient operating humidity |
5 to 95% noncondensing |
|
Certifications |
CE, FCC, IC |
|
NDAA Compliant |
Yes |
