Description
Wireless LAN Controller
- Managed up to 300 APs
- Up to 10,000 local accounts
- 2 x GbE or 2 x 1GbE SFP WAN port
- 8 x GbE LAN port
- Rack Mount
The Edgecore EWS5203 is an enterprise-grade wireless LAN controller that provides establishments such as hotels, universities, or even complete municipalities with a comprehensive set of managed Wi-Fi features at a competitive license-free price point. With AP management, user authentication, policy assignment, traffic shaping, firewall features, and much more all packaged into a single box, the EWS5203 provides network administrators with a reliable, easy-to-use, and centralized management console for an entire organization’s wireless network infrastructure.
The EWS5203 is capable of managing up to 300 ECW/ECWO-series Wireless Access Points and can be directly integrated with Edgecore’s Switches, all of which can be deployed and configured easily by anyone, including non-wireless savvy users. For example, automated AP discovery prevents network administrators from having to go through the hassle of individually adding and configuring each access point. Access points as well as connected Wi-Fi devices can then be monitored and managed from a centralized point, with extensive logging & reporting features to assist in troubleshooting and maintenance.
As Wi-Fi enabled handheld devices such as smartphones and tablets become ever so prevalent in our daily lives, businesses and network operators alike are faced with a mind-boggling dilemma – how to simultaneously address the needs of BYOD (Bring Your Own Device), manage Wi-Fi users, and maintain network service quality for mission critical applications. The EWS5203 is designed exactly with these requirements in mind, and with a total cost of ownership that satisfies even the most price conscious, organizations are guaranteed to receive an unmatched ROI on their wireless LAN infrastructure.
|
HARDWARE |
|
|
Form Factor: |
• 19” (1U) Rack Mount (Mounting bracket included) |
|
Dimensions (W x D x H): |
• 42.6 cm x 27.0 cm x 4.4 cm |
|
Weight: |
• 2.64 kg |
|
Power: |
• Input: 100-240 VAC, 50/60 Hz (Power cord included) |
|
LED Indicators: |
• Power |
|
Buttons: |
• Reset |
|
Environmental Conditions: |
• Operating Temperature: 0°C (32°F) to 40°C (104°F) |
|
INTERFACES |
|
|
Interfaces |
• WAN: 2 x 10/100/1000Base-T Ethernet, Auto-MDIX, RJ-45; or 2 x SFP |
|
SYSTEM CAPACITY |
|
|
Managed APs: |
• Up to 300 |
|
Local Accounts: |
• Up to 10,000 |
|
On-Demand Accounts: |
• Up to 10,000 |
|
Managed Switches: |
• 80 |
|
Max. Number of Online Users: |
• 3,000 |
|
USER SECURITY |
|
|
Authentication Types: |
• 802.1X |
|
Authentication Servers: |
• Local |
|
ACCOUNT GENERATION |
|
|
On-demand Account: |
• SMS registration |
|
Guest Wi-Fi Account: |
• Limitation by duration and volume |
|
NETWORK SECURITY |
|
|
VPN: |
• Remote |
|
Tunneling Protocols: |
• IPSec |
|
Network Isolation: |
• Intra-VLAN or Port |
|
Certificates: |
• Built-in Root CA |
|
Device Mobility: |
• Fast Roaming Between Access Points |
|
SYSTEM MANAGEMENT |
|
|
System Management |
• Browser-Based Configuration |
|
Administrator Accounts: |
• Multiple tiered access privileges |
|
System Time: |
• NTP synchronization |
|
Network Utilities: |
• Built-in packet capture |
|
AP MANAGEMENT |
|
|
AP Management |
• Automatic AP Discovery |
|
Individual AP Information: |
• Associated Clients |
|
INVENTORY MANAGEMENT |
|
|
AP Planning Type: |
• New Stock |
|
AP Entry Preparation: |
• CSV file uploadable |
|
SWITCH MANAGEMENT |
|
|
Switch Management |
• Automatic Switch Discovery |
|
USER MANAGEMENT |
|
|
User Policy Assignment: |
• Role-based |
|
IP Address Reassignment: |
• Allow clients to obtain different IP addresses |
|
NETWORK SERVICES |
|
|
Redundancy (High Availability): |
• N+1 with automatic synchronization |
|
Internet Protocols Supported: |
• IPv4 |
|
Billing Quota Types: |
• By duration |
|
SYSTEM & NEWORK STATUS |
|
|
System & Nework Status |
• System Dashboard |
|
NETWORK ACTIVITY LOGS |
|
|
Network Activity Logs |
• System Log (SYSLOG) |
|
Warranty |
|
|
Warranty |
1 Year |
