Applied Models

Supports creating volumes across different units

21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+
19 series:RS1619xs+
18 series:RS3618xs, RS2818RP+, RS2418RP+, RS2418+
17 series:RS4017xs+, RS3617xs+, RS3617RPxs, RS3617xs
16 series:RS2416RP+, RS2416+
14 series:RS3614xs+, RS3614RPxs, RS3614xs, RS2414RP+, RS2414+
13 series:RS3413xs+
12 series:RS3412RPxs, RS3412xs, RS2212RP+, RS2212+
11 series:RS3411RPxs, RS3411xs, RS2211RP+, RS2211+

Notes

To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit.
DSM version requirement: 6.0.1-7393 or later version

Storage

Drive Bays

12

Drive Type (See all supported drives)

3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD

Hot Swappable Drive*

RAID Management through Synology DSM

✓

Notes

Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.

External Ports

Expansion Port

1

Appearance

Size (Height x Width x Depth)

88 mm x 430.5 mm x 664 mm

Size (Height x Width x Depth) (with server ears)

88 mm x 482 mm x 696 mm

Weight

12.7 kg

Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKS-02)

Notes

The rail kit is sold separately

Power

Power Recovery

Synchronized with the Synology RackStation

Power Supply Unit / Adapter

500 W

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

68.60 W (Access)
27.45 W (HDD Hibernation)

British Thermal Unit

234.23 BTU/hr (Access)
93.73 BTU/hr (HDD Hibernation)

Redundant Power Supply

✓

Notes

Temperature

Operating Temperature

5°C to 35°C (40°F to 95°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Others

System Fan

80 mm x 80 mm x 3 pcs

Easy Replacement System Fan

✓

Noise Level*

54.6 dB(A)

Notes

Certification

Certification

FCC
CE
BSMI
EAC
RCM
KC

Warranty

Warranty

5 Years

Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment

RoHS Compliant

Packaging Content

Packaging Content

Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Expansion Cable: Infiniband X 1
Quick Installation Guide X 1

Optional Accessories

Optional Accessories

Enterprise Series 3.5" SATA HDD: HAT5300 Series
Plus Series 3.5" SATA HDD: HAT3300 Series
Enterprise Series 2.5" SATA SSD: SAT5200 Series
Rail Kit Sliding: RKS-02
