Technical

Dimensions

92 x 60 x 33 mm (3.6 x 2.4 x 1.3")

Weight

159 g (5.6 oz)

Output voltage

48V DC @ 0.5A

LAN activity indicator

No

Gigabit LAN port

Yes

Remote reset capability

No

Reset button

No

Rated voltage

100-240V AC @ 50/60Hz

Input current

0.6A @ 120V AC, 0.4A @ 240V AC

Inrush current

<65A Peak @ 120V AC, <130A peak @ 230V AC

Efficiency

80+%

Output ripple

1% Max.

Switching frequency

65 kHz

Line regulation

≤ 3%

Load regulation

≤ 5%

2-pair powering

Pins 4, 5 (+) and Pins 7, 8 (-)

4-pair powering

–

Storage temperature

-30 to 70°C (-22 to 158° F)

Ambient operating temperature

0 to 40° C (32 to 104° F)

Ambient operating humidity

35 to 95% noncondensing

AC connector

IEC-320 C6

Data IN / PoE

RJ45 shielded socket

Surge protection

Difference and common mode

Clamping protection

11V data, 60V power

Max. surge discharge

1500A (8/20 μs) power

Peak pulse current

36A (10/1000 μs) data

Shunt capacitance

<5 pF data

Response time

<1 ns

Certifications

CE, FCC, IC, UL

NDAA Compliant

Yes
