CPU

CPU Model

AMD Ryzen V1500B

CPU Quantity

1

CPU Cores

4

CPU Threads

8

CPU Architecture

64-bit

CPU Frequency

2.2 GHz

Hardware Encryption Engine

✓

Memory

System Memory

2 GB DDR4 ECC SODIMM

Total Memory Slots

2

Maximum Memory Capacity

32 GB (16 GB x 2)

Notes

Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations.

Storage

Drive Bays

4

Maximum Drive Bays with Expansion Unit

8 (RX418 x 1)

Drive Type (See all supported drives)

3.5" SATA HDD
2.5" SATA SSD

Hot Swappable Drive*

✓

External Ports

RJ-45 1GbE LAN Port

4

USB 3.2 Gen 1 Port

2

Expansion Port

1

Expansion Port Type

eSATA

Notes

MTU value of 1GbE LAN port has a limit of 1500.

PCIe

PCIe Expansion

1 x Gen3 x8 slot (x4 link)

Appearance

Form Factor (RU)

Size (Height x Width x Depth)

44 mm x 480 mm x 518.6 mm

Weight

8.0 kg

Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)

Notes

The rail kit is sold separately

Others

System Fan

40 mm x 40 mm x 2 pcs

Fan Speed Mode

Full-Speed Mode
Cool Mode
Quiet Mode

Power Recovery

✓

Noise Level*

38.8 dB(A)

Scheduled Power On / Off

✓

Wake on LAN / WAN

✓

Power Supply Unit / Adapter

150 watts

Redundant Power Supply

✓

AC Input Power Voltage

100 V to 240 V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

47.69 watts (Access)
16.7 watts (HDD Hibernation)

British Thermal Unit

162.83 BTU/hr (Access)
57.02 BTU/hr (HDD Hibernation)

Notes

For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Certification

Certification

FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
BIS
UL

Warranty

Warranty

3-year hardware warranty

Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Extended Warranty Plus is only available in Europe and North America. Refer to the Extended Warranty Plus website for details on supported countries/regions. (Learn more)

Environment

Environment

RoHS Compliant

Packaging Content

Packaging Content

Main Unit X 1
Accessory Pack X 1
AC Power Cord X 2
Quick Installation Guide X 1

Optional Accessories

Optional Accessories

DDR4 ECC SODIMM: D4ES02-4G/D4ES02-8G/D4ES03-16G
Expansion Units: RX418
Enterprise Series 3.5" SATA HDD: HAT5300 Series
Plus Series 3.5" SATA HDD: HAT3300 Series
Enterprise Series 2.5" SATA SSD: SAT5200 Series
M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1
M.2 SSD Adapter Card: M2D20/M2D18
25GbE Network Interface Card: E25G30-F2
10GbE Network Interface Card: E10G30-F2/E10G30-T2/E10G18-T1
Rail Kit Sliding: RKS-02
Rail Kit Mounted: RKM114*

Notes

Certain items may not be available in your location. Please contact your local distributors for more information.
