Description
PoE plug-and-play notification device, designed to pair with a UniFi doorbell or door access hub.
|
Mechanical |
|
|
Dimensions |
Device: Ø62 x 54 mm (Ø2.5 x 2.1") |
|
In-wall mount: Ø89 x 63.1 mm (Ø3.5 x 2.5") |
|
|
On-wall Mount: Ø62 x 20.2 mm (Ø2.5 x 0.8") |
|
|
Weight |
Device: 158 g (5.6 oz) |
|
In-wall mount: 91 g (3.2 oz) |
|
|
On-wall mount: 28 g (1 oz) |
|
|
Enclosure material |
Polycarbonate, aluminum alloy |
|
Mount material |
Polycarbonate, zinc alloy |
|
System |
|
|
Networking interface |
10/100 MbE port |
|
Power method |
PoE |
|
Supported voltage range |
44—57V DC |
|
Max. power consumption |
3W |
|
ESD/EMP protection |
Air: ± 8kV, contact: ± 4kV |
|
LED |
R/G/B/W |
|
Button |
Factory reset |
|
Ambient operating temperature |
0 to 40° C (32 to 104° F) |
|
Ambient operating humidity |
10 to 90% noncondensing |
|
Certifications |
CE, FCC, IC |
|
NDAA Compliant |
Yes |
|
Audio |
|
|
Speaker |
Yes |
|
Buzzer |
Yes |
|
Software |
|
|
Web application |
UniFi Protect |
|
UniFi Access |
|
|
Mobile app |
UniFi Protect iOS™ and Android™ |
