Description
10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
|
Overview |
||
|
Dimensions |
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
|
|
UniFi Application Suite |
||
|
Network |
✓ |
|
|
Protect |
✓ |
|
|
Access |
✓ |
|
|
Talk |
✓ |
|
|
Connect |
✓ |
|
|
Managed UniFi Devices |
200+ |
|
|
Managed Cameras |
(50) HD (25) 2K (15) 4K |
|
|
Simultaneous Users Connected |
2,000+ |
|
|
Max. WAN Port Count |
8 |
|
|
Default WAN Ports |
(1) 10G SFP+ (1) 2.5 GbE RJ45 |
|
|
Port Layout |
||
|
1 GbE RJ45 |
8 (1G/100M/10M) |
|
|
2.5 GbE RJ45 |
1 (2.5G/1G/100M/10M) |
|
|
10G SFP+ |
2 (10G/1G) |
|
|
IDS/IPS Throughput |
5 Gbps |
|
|
Form Factor |
Rack mount (1U) |
|
|
Redundancy |
Shadow Mode (VRRP) Gateway Failover DC Power Backup |
|
|
Security |
||
|
Stateful Firewall |
✓ |
|
|
Application-Aware Layer 7 Firewall |
✓ |
|
|
DPI & Traffic Identification |
✓ |
|
|
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) |
✓ |
|
|
Content Filtering |
✓ |
|
|
Intrusion Prevention (IPS/IDS) |
✓ |
|
|
Ad Blocking |
✓ |
|
|
IDS/IPS Signatures |
55,000+ with CyberSecure |
|
|
VLAN/Subnet-based Traffic Segmentation |
✓ |
|
|
VPN & SD-WAN |
||
|
License-Free SD-WAN |
✓ |
|
|
Site-to-Site VPN |
||
|
Site Magic |
✓ |
|
|
IPsec |
✓ |
|
|
OpenVPN |
✓ |
|
|
VPN Server |
||
|
Identity Endpoint One-Click VPN |
✓ |
|
|
Teleport Zero-Configuration VPN |
✓ |
|
|
WireGuard |
✓ |
|
|
OpenVPN |
✓ |
|
|
L2TP |
✓ |
|
|
VPN Client |
||
|
OpenVPN |
✓ |
|
|
WireGuard |
✓ |
|
|
Networking |
||
|
Multi-WAN Load Balancing |
✓ |
|
|
Shadow Mode (VRRP) High Availability |
✓ |
|
|
Dynamic Routing |
||
|
OSPF |
✓ |
|
|
BGP |
✓ |
|
|
Advanced QoS |
✓ |
|
|
Multicast DNS (mDNS) |
✓ |
|
|
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) |
✓ |
|
|
Integrated RADIUS Server |
✓ |
|
|
RADIUS over TLS (RadSec) |
✓ |
|
|
Additional Internet Failover with UniFi LTE Backup |
✓ |
|
|
Internet Quality and Outage Reporting |
✓ |
|
|
MAC Address Table Size |
4000 |
|
|
Policy-based WAN and VPN Routing |
✓ |
|
|
Customizable DHCP Server |
✓ |
|
|
IPv6 ISP Support |
✓ |
|
|
IGMP Proxy |
✓ |
|
|
Hardware |
||
|
NVR Storage |
(2) 3.5" NVR HDD bays Built-in 128 GB SSD for Faster Experience |
|
|
Max. Power Consumption |
60W |
|
|
Power Method |
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
|
|
Power Supply |
AC/DC, internal, 100W |
|
|
Supported Voltage Range |
100—240V AC |
|
|
Processor |
Quad-core ARM® Cortex®-A57 at 2.0 GHz |
|
|
System Memory |
8 GB |
|
|
On-board Storage |
32 GB eMMC 128 GB SSD (Integrated) |
|
|
Weight |
4.7 kg (10.4 lb) |
|
|
Enclosure Material |
Aluminium CNC, SGCC steel |
|
|
Mount Material |
SGCC steel |
|
|
LCM Display |
1.3" touchscreen |
|
|
Management |
Ethernet Bluetooth |
|
|
LEDs |
||
|
Ethernet |
✓ |
|
|
SFP+ |
✓ |
|
|
RPS |
✓ |
|
|
PSU |
✓ |
|
|
HDD |
✓ |
|
|
Button |
(1) Factory-reset |
|
|
ESD/EMP Protection |
Air: ± 15kV, contact: ± 8kV |
|
|
Ambient Operating Temperature |
-10 to 40° C (14 to 104° F) |
|
|
Ambient Operating Humidity |
5 to 95% noncondensing |
|
|
NDAA Compliant |
✓ |
|
|
Certifications |
CE, FCC, IC, Anatel, SRRC |
|
