Description
Desktop UniFi Cloud Gateway with integrated WiFi 6 and PoE switching.
Note. UniFi application support consists of UniFi Network plus two of Protect, Access, Talk, or Connect.
GbE RJ45 WAN port internet speeds up to 700 Mbps.
|
Overview |
||
|
Dimensions |
Ø110 x 184.1 mm (Ø4.3 x 7.3") |
|
|
UniFi Application Suite |
||
|
Network |
✓ |
|
|
Protect |
✓ |
|
|
Access |
✓ |
|
|
Talk |
✓ |
|
|
Connect |
✓ |
|
|
Managed UniFi Devices |
20+ |
|
|
Managed Cameras |
(5) HD (2) 2K (1) 4K |
|
|
Simultaneous Users Connected |
150+ |
|
|
Max. WAN Port Count |
1 |
|
|
Default WAN Ports |
(1) GbE RJ45 |
|
|
Port Layout |
||
|
1 GbE RJ45 |
5 (2 PoE) (1G/100M/10M) |
|
|
IDS/IPS Throughput |
1 Gbps |
|
|
Form Factor |
Compact desktop |
|
|
Coverage Area |
140 m² (1,500 ft²) |
|
|
Security |
||
|
Stateful Firewall |
✓ |
|
|
Application-Aware Layer 7 Firewall |
✓ |
|
|
DPI & Traffic Identification |
✓ |
|
|
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) |
✓ |
|
|
Content Filtering |
✓ |
|
|
Intrusion Prevention (IPS/IDS) |
✓ |
|
|
Ad Blocking |
✓ |
|
|
IDS/IPS Signatures |
20,000+ with CyberSecure |
|
|
VLAN/Subnet-based Traffic Segmentation |
✓ |
|
|
VPN & SD-WAN |
||
|
License-Free SD-WAN |
✓ |
|
|
Site-to-Site VPN |
||
|
Site Magic |
✓ |
|
|
IPsec |
✓ |
|
|
OpenVPN |
✓ |
|
|
VPN Server |
||
|
Identity Endpoint One-Click VPN |
✓ |
|
|
Teleport Zero-Configuration VPN |
✓ |
|
|
WireGuard |
✓ |
|
|
OpenVPN |
✓ |
|
|
L2TP |
✓ |
|
|
VPN Client |
||
|
OpenVPN |
✓ |
|
|
WireGuard |
✓ |
|
|
Networking |
||
|
Dynamic Routing |
||
|
OSPF |
✓ |
|
|
Advanced QoS |
✓ |
|
|
Multicast DNS (mDNS) |
✓ |
|
|
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) |
✓ |
|
|
Integrated RADIUS Server |
✓ |
|
|
RADIUS over TLS (RadSec) |
✓ |
|
|
Additional Internet Failover with UniFi LTE Backup |
✓ |
|
|
Internet Quality and Outage Reporting |
✓ |
|
|
MAC Address Table Size |
1000 |
|
|
Policy-based WAN and VPN Routing |
✓ |
|
|
Customizable DHCP Server |
✓ |
|
|
IPv6 ISP Support |
✓ |
|
|
IGMP Proxy |
✓ |
|
|
Integrated WiFi |
||
|
WiFi Standard |
802.11a/b/g/n/ac/ax (WiFi 6) |
|
|
Throughput |
||
|
5 GHz |
2.4 Gbps |
|
|
2.4 GHz |
600 Mbps |
|
|
MIMO |
||
|
5 GHz |
4 x 4 (DL/UL MU-MIMO) |
|
|
2.4 GHz |
4 x 4 (DL/UL MU-MIMO) |
|
|
Antenna Gain |
||
|
5 GHz |
4.3 dBi |
|
|
2.4 GHz |
3.4 dBi |
|
|
Max. TX Power |
||
|
5 GHz |
26 dBm |
|
|
2.4 GHz |
26 dBm |
|
|
Wireless Security |
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
|
|
Max. BSSIDs |
8 per Radio |
|
|
Supported Data Rates |
||
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
|
802.11b |
1, 2, 5.5, 11 Mbps |
|
|
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
|
802.11n |
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40) |
|
|
802.11ac (WiFi 5) |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) |
|
|
802.11ax (WiFi 6) |
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) |
|
|
Hardware |
||
|
NVR Storage |
Built-in 128 GB SSD for detection recordings |
|
|
Expansion Slot |
MicroSD Card |
|
|
PoE Budget |
40W |
|
|
Max. PoE Wattage per Port by PSE |
||
|
PoE |
15.4W |
|
|
Voltage Range PoE Mode |
44-57V |
|
|
Max. Power Consumption |
19.37W (Excluding PoE Output) |
|
|
Power Method |
Universal AC input, 100—240VAC, 1.1A Max, 50/60 Hz |
|
|
Power Supply |
AC/DC, Internal, 50W |
|
|
Supported Voltage Range |
100—240V AC |
|
|
Processor |
Dual-core Arm® Cortex® A53 at 1.35 GHz |
|
|
Weight |
1.2 kg (2.5 lb) |
|
|
Enclosure Material |
Polycarbonate |
|
|
LCM Display |
0.96" status display |
|
|
Management |
Ethernet Bluetooth |
|
|
Button |
(1) Factory-reset |
|
|
Ambient Operating Temperature |
-10 to 45° C (14 to 113° F) |
|
|
Ambient Operating Humidity |
5 to 95% noncondensing |
|
|
NDAA Compliant |
✓ |
|
|
Certifications |
CE, FCC, IC |
|
|
Software |
||
|
VLAN |
802.1Q |
|
|
Guest Traffic Isolation |
✓ |
|
