Description
An 8-port, Layer 3 switch with 2.5 GbE PoE+ output.
|
Overview |
||
|
Dimensions |
200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
|
|
Port Layout |
||
|
2.5 GbE RJ45 |
8 (All PoE+) (2.5G/1G/100M) |
|
|
10G SFP+ |
2 |
|
|
Max. PoE Output |
Up to PoE+ |
|
|
Total PoE Availability |
||
|
120W |
||
|
Layer 3 |
✓ |
|
|
Form Factor |
Compact desktop |
|
|
Performance |
||
|
Switching Capacity |
80 Gbps |
|
|
Total Non-Blocking Throughput |
40 Gbps |
|
|
Forwarding Rate |
60 Mpps |
|
|
Supported VLANs |
1000 |
|
|
MAC Address Table Size |
16000 |
|
|
L3 Table Size |
||
|
ARP Entries |
512 |
|
|
IPv4 Routes |
512 |
|
|
Packet Buffer Size |
1.5 MB |
|
|
Access Lists |
||
|
IPv4 |
12 |
|
|
MAC |
10 |
|
|
Layer 3 Features |
||
|
DHCP Server (Local Networks) |
✓ |
|
|
Inter-VLAN Routing (Local Networks) |
✓ |
|
|
Static Routing (Local Networks) |
✓ |
|
|
Layer 2 Features |
||
|
LACP Port Aggregation |
✓ |
|
|
STP & RSTP |
✓ |
|
|
Advanced IGMP Configuration (Querier, Fast Leave, Router Port) |
✓ |
|
|
IGMP Snooping |
✓ |
|
|
802.1X Control |
✓ |
|
|
MAC-Based ACLs & Device Isolation |
✓ |
|
|
DHCP Snooping & Guarding |
✓ |
|
|
Egress Rate Limit |
✓ |
|
|
Flow Control |
✓ |
|
|
Storm Control |
✓ |
|
|
Multicast & Broadcast Rate Limiting |
✓ |
|
|
MAC Address Blocking |
✓ |
|
|
IP-Based ACLs & Network Isolation |
✓ |
|
|
MAC-Based Port Restriction |
✓ |
|
|
Port Isolation |
✓ |
|
|
Port Mirroring |
✓ |
|
|
Jumbo Frames |
✓ |
|
|
LLDP-MED |
✓ |
|
|
Voice VLAN |
✓ |
|
|
Loop Protection |
✓ |
|
|
Hardware |
||
|
PoE Ports |
||
|
PoE+ |
8 |
|
|
Max. PoE Wattage per Port by PSE |
||
|
PoE+ |
32W |
|
|
Max. Power Consumption |
30W (Excluding PoE Output) 150W (Including PoE Output) |
|
|
Power Method |
Universal input, 100—240V AC, 50/60 Hz |
|
|
Power Input Method |
AC input |
|
|
Power Supply |
AC/DC, internal, 150W |
|
|
Supported Voltage Range |
100—240V AC |
|
|
Management |
Ethernet AR |
|
|
Heat Dissipation (Excluding PoE Output) |
102.36 BTU/hr |
|
|
Weight |
2.4 kg (5.3 lb) |
|
|
Enclosure Material |
Polycarbonate |
|
|
Mount Material |
Polycarbonate |
|
|
Supported Rack Depth |
400~1200 mm (15.7-47.2") |
|
|
LCM Display |
1.3" touchscreen |
|
|
ESD/EMP Protection |
Air: ± 16kV, contact: ± 12kV |
|
|
Ambient Operating Temperature |
-5 to 45° C (23 to 113° F) |
|
|
Ambient Operating Humidity |
10 to 90% noncondensing |
|
|
NDAA Compliant |
✓ |
|
|
Certifications |
CE, FCC, IC, Anatel |
|
|
Software |
||
|
Application Requirements |
||
|
UniFi Network |
Version 6.3.51 and later |
|
