Description
Router with a built-in Layer 2 switch, (10) Gigabit RJ45 ports, and (2) SFP ports, each equipped with a 24V, two-pair PoE output.
|
Mechanical |
|
|
Dimensions |
268.1 x 136.5 x 31.1 mm (10.6 x 5.4 x 1.2") |
|
Weight |
700 g (1.5 lb) |
|
Hardware |
|
|
Processor |
4-core 1 GHz MIPS64 |
|
System memory |
1 GB DDR3 RAM |
|
On-board flash storage |
4 GB eMMC, 8 MB SPI NOR |
|
Networking interface |
(10) 10/100/1000 RJ45 ports |
|
(2) 1 Gbps SFP ports |
|
|
Management interface |
(1) RJ45 serial port |
|
PoE interface |
(10) 24V passive PoE ports, 2-pair (Pins 4, 5+; 7, 8-) |
|
Power method |
AC/DC power adapter, 60W, 24V DC, 2.5A (Included) |
|
Power supply |
External AC/DC adapter |
|
Supported voltage range |
9–30V DC |
|
Max. power consumption |
20W (Excludes PoE output) |
|
Passive PoE Max. wattage per port |
17W (24V) |
|
Passive PoE voltage range |
20–30V |
|
ESD/EMP protection |
Air: ± 24 kV, contact: ± 24 kV |
|
Button |
Fctory reset |
|
LEDs |
System: power |
|
Data ports: PoE, speed/link/activity |
|
|
SFP port: link/activity |
|
|
Ambient operating temperature |
-10 to 40° C (14 to 104° F) |
|
Ambient operating humidity |
10 to 90% noncondensing |
|
Certifications |
CE, FCC, IC |
|
NDAA Compliant |
Yes |
