CPU

CPU Model

AMD Ryzen R1600

CPU Quantity

1

CPU Cores

2

CPU Threads

4

CPU Architecture

64-bit

CPU Frequency

2.6 (base) / 3.1 (turbo) GHz

Hardware Encryption Engine

✓

Memory

System Memory

2 GB DDR4 ECC

Notes

Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.

Storage

Drive Bays

4

Drive Type (See all supported drives)

3.5" SATA HDD
2.5" SATA SSD

Hot Swappable Drive*

✓

External Ports

RJ-45 1GbE LAN Port

2

USB 3.2 Gen 1 Port

1

Notes

This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.

PCIe

✓

PCIe Expansion

1 x Gen3 x2 network upgrade slot

Appearance

Form Factor (RU)

1U

Size (Height x Width x Depth)

44 mm x 478 mm x 327.5 mm

Weight

4.38 kg

Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)
2-post 19" rack (direct mounting)

Notes

The rail kit is sold separately

Others

System Fan

40 mm x 40 mm x 3 pcs

Fan Speed Mode

Full-Speed Mode
Cool Mode
Quiet Mode

Power Recovery

✓

Noise Level*

28.5 dB(A)

Scheduled Power On / Off

✓

Wake on LAN / WAN

✓

Power Supply Unit / Adapter

100 watts

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

37.93 watts (Access)
13.43 watts (HDD Hibernation)

British Thermal Unit

129.42 BTU/hr (Access)
45.83 BTU/hr (HDD Hibernation)

Notes

For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature

0°C to 35°C (32°F to 95°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Certification

Certification

FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
BIS

Warranty

Warranty

3-year hardware warranty

Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Extended Warranty Plus is only available in Europe and North America. EW201/EW202 is only available in Asia, Africa, and Oceania. For exact availability information please visit their respective websites.

Environment

Environment

RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Cord X 1
Quick Installation Guide X 1

Optional Accessories

Optional Accessories

Enterprise Series 3.5" SATA HDD: HAT5300 Series
Plus Series 3.5" SATA HDD: HAT3300 Series
Enterprise Series 2.5" SATA SSD: SAT5200 Series
10GbE Network Upgrade Module: E10G22-T1-Mini
Rail Kit Sliding: RKS-02
Rail Kit Mounted: RKM114*

Notes

Certain items may not be available in your location. Please contact your local distributors for more information.
