Description
BaseStation that supports speeds of up to 150+ Mbps real TCP/IP throughput.
|
Mechanical |
|
|
Dimensions |
160 x 80 x 30 mm (6.3 x 3.2 x 1.2") |
|
Weight |
500 g (1.1 lb) |
|
Enclosure material |
UV-stabilized plastic |
|
Hardware |
|
|
Networking interface |
(1) 10/100 MbE RJ45 port |
|
Power method |
Passive PoE 2-pair (4, 5+; 7, 8) |
|
Power supply |
24V, 1A PoE adapter (Included) |
|
Max. power consumption |
6.5W |
|
Supported voltage range |
20–27V DC |
|
RF connectors |
(2) RP-SMA (waterproof) |
|
Operating frequency |
3400 - 3730 MHz* |
|
*RocketM3 not supported in the USA. |
|
|
Shock and vibration |
ETSI300-019-1.4 |
|
Ambient operating temperature |
-30 to 75° C (-22 to 167° F) |
|
Ambient operating humidity |
5 to 95% noncondensing |
|
Certifications |
CE, FCC, IC |
|
Software |
|
|
Operating mode |
Access Point, station |
|
Software management |
Bluetooth management for easy setup over UISP Mobile app |
|
WEB UI |
|
|
Minimum software requirements |
Any modern web browser/iOS™ or Android™ based smartphone |
|
Security |
WPA2 AES only |
|
Services |
Services web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing |
|
Utilities |
Antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test |
|
QoS |
Supports packet level classification WMM and user customer level: High/Medium/Low |
|
NDAA Compliant |
Yes |
