Controller

Number of Controller Module

2

CPU

CPU Model

Intel Xeon D-1521

CPU Quantity

1 (per controller)

CPU Cores

4

CPU Threads

8

CPU Architecture

64-bit

CPU Frequency

2.4 (base) / 2.7 (turbo) GHz

Hardware Encryption Engine

✓

Memory

System Memory

8 GB DDR4 ECC UDIMM (per controller)

Total Memory Slots

4 (per controller)

Maximum Memory Capacity

64 GB (16 GB x 4) (per controller)

Notes

Synology may revise pre-installed memory module specifications in response to component lifecycle and supply conditions. All revised components undergo the same rigorous validation to ensure equivalent compatibility, stability, and performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations.

Storage

Drive Bays

12

Maximum Drive Bays with Expansion Unit

36 (RXD1219sas x 2)

Drive Type (See all supported drives)

2.5” dual-port SAS SSD
2.5” dual-port SAS HDD
3.5” dual-port SAS HDD

Hot Swappable Drive*

✓

External Ports

RJ-45 1GbE LAN Port

2 (per controller)

RJ-45 10GbE LAN Port

1 (per controller)

Expansion Port

1 (per controller)

Expansion Port Type

Mini-SAS HD

PCIe

PCIe Expansion

1 x Gen3 x8 slot (x8 link) (per controller)

Appearance

Form Factor (RU)

2U

Size (Height x Width x Depth)

88 mm x 482 mm x 724 mm

Weight

19.7 kg

Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKS-02)

Notes

The rail kit is sold separately

Others

System Fan

60 mm x 60 mm x 2 pcs

Fan Speed Mode

Full-Speed Mode
Cool Mode
Quiet Mode

Easy Replacement System Fan

✓

Power Recovery

✓

Noise Level*

51.3 dB(A)

Power Supply Unit / Adapter

500 watts

Redundant Power Supply

✓

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption

417.48 watts (Access)

British Thermal Unit

1425.45 BTU/hr (Access)

Notes

Power consumption is measured when it is fully loaded with Seagate ST3600057SS hard drive(s).
Noise Level Testing Environment: Fully loaded with Seagate ST8000NM0075 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology server at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

Temperature

Operating Temperature

0°C to 35°C (32°F to 95°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Certification

Certification

FCC
CE
BSMI
VCCI
RCM
EAC
CCC
BIS

Warranty

Warranty

5 Years

Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment

RoHS Compliant

Packaging Content

Packaging Content

Main Unit X 1
Accessory Pack X 1
AC Power Cord X 2
Quick Installation Guide X 1

Optional Accessories

Optional Accessories

DDR4 ECC UDIMM: D4EC-2666-8G/D4EC-2666-16G
Expansion Units: RXD1219sas
Enterprise Series 3.5" SAS HDD: HAS5300 Series
25GbE Network Interface Card: E25G30-F2
10GbE Network Interface Card: E10G30-F2/E10G30-T2/E10G18-T1
Rail Kit Sliding: RKS-02

Notes

For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations.
