Description
Eight-port, Layer 2, Gigabit PoE switch designed for MicroPoP applications and building secure, high-performance networks.
|
Mechanical |
|
|
Dimensions |
210.4 x 95 x 29 mm (8.3 x 3.7 x 1.1") |
|
Weight |
610 g (1.3 lb) |
|
Enclosure material |
Polycarbonate |
|
Hardware |
|
|
Total non-blocking throughput |
9 Gbps |
|
Switching capacity |
18 Gbps |
|
Forwarding rate |
13.392 Mpps |
|
Networking interface |
(8) GbE RJ45 ports |
|
(1) 1G SFP port |
|
|
Management interface |
Ethernet In-band |
|
Bluetooth BLE |
|
|
Power method |
External AC/DC adapter |
|
Power supply |
27V DC, 4.4A power adapter (included) |
|
Supported voltage range |
24—28V DC |
|
Max. power consumption |
8W (Excluding PoE output) |
|
ESD/EMP protection |
Air: ± 15kV, contact: ± 8kV |
|
Ambient operating temperature |
-10 to 50° C (14 to 122° F) |
|
Ambient operating humidity |
5 to 95% non-condensing |
|
Certifications |
CE, FCC, IC |
|
PoE |
|
|
PoE interface |
(8) 27V passive PoE: 2-pair (pins 4, 5+/7, 8-) or 4-pair (pins 1, 2, 4, 5+/3, 6, 7, 8-) |
|
Total available PoE |
110W |
|
Max. passive PoE wattage per port |
30W/27V DC |
|
Passive PoE voltage range |
27V DC |
|
LEDs |
|
|
RJ45 data ports |
PoE |
|
Speed/link/activity |
|
|
SFP data ports |
Link/activity |
|
Software |
|
|
Management application |
UISP: Version 1.4.0 and later |
|
NDAA Compliant |
Yes |
