Description
0G multi-WAN independent gateway with UniFi Power Backup support designed to protect large-scale networks.
Managed by a CloudKey, Official UniFi Hosting, or UniFi Network Server
3.5+ Gbps routing with IDS/IPS
(1) 10G SFP+* and (1) GbE WAN port
(1) 10G SFP+* and (1) GbE LAN port
UniFi Power Backup ready
*Pair with an official SFP+ Module or SFP+ to RJ45 Adapter for the best experience.
|
Overview |
||
|
Dimensions |
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
|
|
Max. WAN Port Count |
3 |
|
|
Default WAN Ports |
(1) 10G SFP+ (1) GbE RJ45 |
|
|
Port Layout |
||
|
10G SFP+ |
2 (10G/1G) |
|
|
IDS/IPS Throughput |
3.5 Gbps |
|
|
Form Factor |
Rack mount (1U) |
|
|
Redundancy |
DC Power Backup |
|
|
Security |
||
|
Stateful Firewall |
✓ |
|
|
Application-Aware Layer 7 Firewall |
✓ |
|
|
DPI & Traffic Identification |
✓ |
|
|
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) |
✓ |
|
|
Content Filtering |
✓ |
|
|
Intrusion Prevention (IPS/IDS) |
✓ |
|
|
Ad Blocking |
✓ |
|
|
IDS/IPS Signatures |
55,000+ With CyberSecure |
|
|
VPN & SD-WAN |
||
|
License-Free SD-WAN |
✓ |
|
|
Site-to-Site VPN |
||
|
Site Magic |
✓ |
|
|
IPsec |
✓ |
|
|
OpenVPN |
✓ |
|
|
VPN Server |
||
|
Teleport Zero-Configuration VPN |
✓ |
|
|
WireGuard |
✓ |
|
|
OpenVPN |
✓ |
|
|
L2TP |
✓ |
|
|
VPN Client |
||
|
OpenVPN |
✓ |
|
|
WireGuard |
✓ |
|
|
Networking |
||
|
Multi-WAN Load Balancing |
✓ |
|
|
Dynamic Routing |
||
|
OSPF |
✓ |
|
|
Advanced QoS |
✓ |
|
|
Multicast DNS (mDNS) |
✓ |
|
|
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) |
✓ |
|
|
Integrated RADIUS Server |
✓ |
|
|
RADIUS over TLS (RadSec) |
✓ |
|
|
Additional Internet Failover with UniFi LTE Backup |
✓ |
|
|
Internet Quality and Outage Reporting |
✓ |
|
|
Hardware |
||
|
Max. Power Consumption |
30W |
|
|
Power Method |
US: (1) Universal AC input, 125V AC, 2.7A Max., 60 Hz (1) RPS DC input, 11.5V DC, 2.87A Worldwide: (1) Universal AC input, 200-240V AC, 1.7A Max., 50/60 Hz (1) RPS DC input, 11.5V DC, 2.87A |
|
|
Power Supply |
AC/DC, internal, 50W |
|
|
Supported Voltage Range |
100—240V AC |
|
|
Processor |
Quad-core ARM® Cortex®-A53 at 1.5 GHz |
|
|
System Memory |
2 GB |
|
|
Weight |
3.4 kg (7.5 lb) |
|
|
Enclosure Material |
Front panel: Aluminum CNC Top cover/base: SGCC steel |
|
|
LCM Display |
1.3" touchscreen |
|
|
Management |
Ethernet |
|
|
LEDs |
||
|
Ethernet |
✓ |
|
|
SFP+ |
✓ |
|
|
RPS |
✓ |
|
|
AC Outlet |
✓ |
|
|
Button |
(1) Factory-reset |
|
|
ESD/EMP Protection |
Air: ± 15kV, contact: ± 8kV |
|
|
Ambient Operating Temperature |
-10 to 40° C (14 to 104° F) |
|
|
Ambient Operating Humidity |
5 to 95% noncondensing |
|
|
NDAA Compliant |
✓ |
|
|
Certifications |
CE, FCC, IC |
|
|
Software |
||
|
Application Requirements |
||
|
UniFi Network |
Version 8.3.32 and later |
|
